Construction tools list for building construction works such as concrete, brick masonry, leveling, wood works, floor works, slab works, brick laying, plastering etc. is provided. Every construction tool is necessary to achieve good results in the whole project.
Along with these tools, the workers should also use some safety tools to prevent them from the unexpected accidents.
Construction Tools List for Building Construction
Some important construction tools and their uses are listed below:
Bolster
Boning rod
Brick hammer
Bump cutter/screed
Chisel
Circular saw
Concrete mixer
Cordless drill
Crowbar
Digging bar
End frames
Float
Gloves
Hand saw
Helmet
Hoe
Iron pan
Jack plane
Ladder
Line and pins
Mason’s square
Measuring box
Measuring tape
Measuring wheel
Pick axe
Plumb bob
Plumb rule
Polishers
Putty knife
Rammer
Rubber Boots
Safety glasses
Safety helmet
Sand screen machine
Scratchers
Sledge hammer
Spade
Spirit level
Straight edge brushes
Tile cutter
Trowel
Vibrator
Wedge
Wheel barrow
Bolster
Bolster is like chisel but it is used to cut bricks. Its cutting edge is wider than the width of brick. It is useful for accurate cutting of bricks.
Bolster
Boning Rods
Boning rods are made of wood and they are T shape. They are used to level the excavated trench throughout its length. Minimum three boning rods are used to level the trench surface.
Boning Rods
Brick Hammer
Brick hammer is used to cut the bricks and also used to push the bricks if they come out of the course line.
Brick Hammer
Bump Cutter
Bump cutter is used to level the concrete surfaces like concrete floors, foundations etc. It is also called screed.
Bump Cutter
Chain Lewis and Pin Lewis
Chain lewis and pin lewis are two different tools which are used to lift heavy stones especially in the construction of stone masonry.
Chain Lewis and Pin Lewis
Chisel
Chisel is generally used in wood work and this must be useful to remove the concrete bumps or excess concrete in hardened surface.
Chisel
Circular Saw
Circular saw used to cut the wood boards, frames etc. It is used when accurate cutting is required in less time. It is safer than hand saw.
Circular Saw
Concrete Mixer
Concrete mixer is machine which mixes the ingredients water, fine aggregate, coarse aggregate and cement to deliver the perfectly mixed concrete.
Concrete Mixer
Also Read: Different Types of Concrete Mixer or Concrete Mixing Machines
Crowbar
Crowbar is used for digging the ground and to remove the roots of trees in the ground, nails etc.
Crow Bar
Digging Bar
Digging bar is solid metal rod with pin shape at the bottom. It is also used to dig the hard surfaces of ground.
Digging Bar
Drill Machine
Drill machine is used to make holes in the walls, slabs, doors, window frames etc.
Drill Machine
End Frames
Their use is similar to the line and pins. But instead of pins, L shaped frames are used at the end of thread which hold the brick work effectively and level the alignment accurately.
End Frames
Float
Float is made of wood which is used to smoothen the plastered concrete surface. It contains handle on its top and smooth wooden surface on its bottom.
Float
Gloves
Gloves are required to prevent the hands from direct contact with cement, paints etc. and to avoid injury while using machines, tools etc.
Gloves
Hand Saw
Hand saw is used to cut the wood materials like doors, windows, slab panels etc.
Hand Saw
Head Pan
Head pan is made of iron which is used to lift the excavated soil or cement or concrete to the working site etc. it is more commonly used in construction sites.
Head Pan
Hoe
Hoe is also used to excavate the soil but in this case the metal plate is provided with acute angle to the wooden handle.
Hoe
Jack Plane
Jack plane is used in the wood work to smoothen the surface of doors and windows etc.
Jack Plane
Ladder
Ladder is also required in construction works. To check slab work, to transport material to the higher floors, to paint the walls etc.
Ladder
Line and Pins
Line and pins consists a thread whose ends are connected with two solid metal rods with pin points. It is used to level the alignment of brick course while brick laying.
Line and Pins
Mason’s Square
Mason’s square is used to achieve perfect right angle at the corner of masonry wall. It is “L” shape. First course is laid properly using Mason’s square then based on the first, remaining layers of bricks are set out.
Mason’s Square
Measuring Box
Measuring box is used to measure the quantity of sand and aggregate used for making concrete. It is of fixed dimensions so, aggregate need not to be weighted for every time. The general dimensions of a measuring box are 300mm X 300mm X 400mm (length x width x depth).
The volume of measuring box is generally 1 Cubic Feet, which makes it easy to measure concrete ratio or mortar ratio.
Measuring Box
Also Read: Concrete Calculator – Calculate Concrete for Slab, Beam, Column and Footings
Measuring Tape
Measuring tape is used to check the thickness, length, widths of masonry walls, foundation beds, excavated trenches etc.
Measuring Tape
Measuring Wheel
Measuring wheel is used to measure the distances or lengths. It contains a wheel of known diameter, which record the no.of complete revolutions from which the distance can be measured. It makes the work easier.
Measuring Wheel
Pick Axe
Pick axe is used to excavate the soil. It is more suitable for hard soil which is quite difficult to dig with spade or hoe.
Pick Axe
Plumb Bob
Plumb bob is used to check the verticality of structures. It contains a solid metal bob connected to the end of a thread. It is also used inn surveying to level the instrument position.
Plumb Bob
Plumb Rule
Plumb rule is used to check the vertical line of wall whether it is perfect vertical or not. It contains a straight wood board with uniform edges. On its center a groove is provided in which plumb bob is situated. When the rule is placed vertically with the wall the plumb bob should be in the groove line otherwise the wall will not be vertical.
Plumb Rule
Polisher
Polisher is used to smoothen the surface of tiles, wood works etc. The smoothening makes them shine and the process is called polishing.
Polisher
Putty Knife
Putty knife is used level the putty finishing and also used to reduce the thickness of finish when it is more thick.
Putty Knife
Earth Rammer
After the excavation of ground, the lower surface may be uneven. To level the surface earth rammer is used. It contains big square shaped block at its end with which the ground is leveled.
Earth Rammer
Rubber Boots
During construction works, legs may damage due to contact with chemical materials like cement or physical accidents. So, for safety rubber shoes are required.
Rubber Boots
Safety Glasses
To prevent the eyes from dust, chemical actions of materials etc. safety glasses should be maintained.
Safety Glasses
Safety Helmet
The safety helmet should be necessary in construction works. Any material or structure may fall from height during construction work. So, to protect the head from injury or any fatal accident, this safety helmet should be used.
Safety Helmet
Sand Screen Machine
The fine aggregate used in concrete should not contain impurities or coarse particles. The sand screen machine is used to screen the sand or fine aggregate before mixing it with concrete. This screen is also used for screening fine sand for plastering work.
Sand Screen Machine
Scratchers
Plastering of a surface is carried out layer wise. Minimum 2 coats are necessary for plastering. To provide the good bond between the coats, bottom layer is scratched with a tool called scratchers.
Scratchers
Sledge Hammer
Sledge hammer is used when the ground is hard and contains rock layers. A large weighted metal head is provided at the wooden handle with which hard layers can be cracked, which makes easy for digging.
Sledge Hammer
Spade
Spade is used to dig the soil for foundation trenches etc. It contains metal plate at the end of long wooden handle.
Spade
Spirit Level
Spirit level is made of wood or hard plastic with bubble tube in the middle. The bubble tube is filled with alcohol partially. So, the air bubble is formed in it.
Spirit level is used in brick masonry to check the level of the surface. The spirit level is placed on surface and bubble is checked. The surface is leveled when the bubble in the tube settles at middle of tube.
Spirit Level
Straight Edge Brushes
Straight edge brushes are used to provide finishing to the plastered surface especially at corners and edges of walls.
Straight Edge Brushes
Tile Cutter
Tile cutter is used to cut the tiles. Sometimes, normal tile size is larger than required at the corners where floor meets the wall in that case tile cutter is useful.
Tile Cutter
Trowel
Trowel is used to lift and apply the cement mortar in small quantities. It is made of steel and wooden handle is provided for holding. The ends of trowel may be pointed or bull nosed.
Trowel
Vibrator
Vibrator is used to compact the concrete by this the air gaps are filled with water and workability varies without adding water to it.
Vibrator
Also Read: Types of Vibrators for Concrete Compaction
Wedge
Wedge is a small hard metal blade which is used to cut the rock surfaces with the help of sledge hammer.
Wedge
Wheel Barrow
Wheel barrow is used to transport bulk weights of materials like cement, sand, concrete mix etc. it contains one or two wheels at its front and two handles at its back which are used to push the wheel barrow.
Wheel Barrow
